Web width | 330mm |
Print width | 320mm |
Unwind Diameter max | 600mm |
Rewind Diameter max | 600mm |
Press Speed max (Production speed depending on process, job etc.) | 60m/min |
Gear Pitch | 1/8" (3.175mm) |
Flexo Print Units (IR dryer): | 6 |
Die-Cutting Units: number | 1 |
Min.Max repeat Print Cylinder | 7" - 13.5" (56T-108T) |
Web Guiding: number | 1 |
Turn Bar: number | 1 |
Lamination Unit: number | 1 |
Waste Rewinder: number | 1 |
Voltage | 3 phase 380V, 50HZ |
Air shafts diameter | 76mm |
Printing plate thickness | 1.7mm |
Plate mounting tape thickness | 0.38mm |
Ceramic anilox roller: number | 6 pcs, customized (200LPI-1000LPI) |
Printing roller: number | 12pcs, customized (56T-108T) |
