Feature

1.Main transmission unit: It uses an AC variable frequency vector control. The glue spreading rubber roller and hot drum are synchronized in terms of speed and use the swing arm to control the tightness and looseness of the film in the channel.

2.Material feeding device: Group one and two feeding devices use a dual station inching reversing and use a double photoelectric edge-correcting device. Automatic tension control is achieved.
3.Material receiving device: It uses a dual station inching reversing and automatic material collecting. A moment motor is involved in material receiving.
4.Rubber spreader: The anilox rollers control the scrapping and inking amount through doctor blades. The rubber roller features a dual air cylinder to increase the pressure while the pressure is also freely adjustable. The laminating film can lift automatically while the dry laminating machine stops.
5.Oven tunnel: The tunnel is divided into three sections, and the temperature in each is controlled independently through an intelligent temperature controller. In addition, these sections are also independently dried by the hot air drying system and hot air is recycled for reuse. The material-protecting roller and the hot drum rotate synchronously.
