Use Anilox roller to spread ink Unwinding and rewinding are controlled by magnetic powder brake and clutch (or by automatic tension controller of Mitsubishi made in Japan-optional) Each printing unit adopt 360 degree for color registration Each printing unit have one IR drier The rubber roller can be break away automatically while parking, and running at a low speed in order to avoid ink being dry The main motor is adopted the import stepless regulation of frequency conversion Unwinding, web gu
Model | ZBS-650 | ZBS-850 |
Printing color number | 4 color~6 color | 4 color~6 color |
Printing speed | 0~60m/min | 0~60m/min |
Max web width | 660mm | 860mm |
Max printing wide | 650mm | 850mm |
Max unwinding diameter | 1400mm | 1400mm |
Max rewinding diameter | 1400mm | 1400mm |
Printing length | 175~380mm | 175~380mm or 250~580mm |
Precision of color register | ±0.1mm | ±0.1mm |
Overall dimension (5 color) | 4000X1700X2700mm | 4000X1900X2700mm |
Machine weight | About 5000kg | About 6000kg |
