a. Servo motor driving system for constant length control ; b. Center computer control(PLC) for main electric control; c. Person-machine interface(touch screen)operation; d. Long service life cutting blade imported from German; e. Automatic patting for paper collecting system, and automatic counting and inserting label to ensure the heaping in order.
Cutting style | Rotary cutting (upper blade rotary, lower blade fixed) |
Max. Cutting width | 1300mm |
Max. diameter of material | ∮900mm |
Cutting length | 450-1000mm |
Cutting thickness range | 30~200gsm |
Max cutting frequency | 200pcs/min |
Speed | ≤200m/min (≤80gsm speed ≤100m/min ) |
Cutting Accuracy | ±0.5mm |
Max height of stacking | 1200mm |
Power supply | AC 380V/3P/50Hz |
Total power | 24KW |
Overall dimensions (L×W×H) | 11000×4000×2300mm 1200×2280×1400mm 1200×2580×1400mm |
Weight | 8000kg |
