GFQ-600-1200 single layer plastic bag making machine can produce T-shirt plastic bags and carrier bags on which there is painting. Frequency conversion motor is used as main motor, and it is more convenient to regulate speed and saves much energy. High performance color detector can ensure high precision heating and sealing length as well as smaller error. Advanced computer also makes it more convenient to regulate plastic bag length.
| Model | GFQ-600 | GFQ-800 | GFQ-1000 | GFQ-1200 |
| Max.Width of bag-making(mm) | 550 | 750 | 950 | 1150 |
| Max.Length of bag-making(mm) | 950 | 950 | 1200 | 2000 |
| Speed of bag-making(pc/min) | 30-120 | 30-100 | 30-100 | 30-80 |
| Power of main motor(kw) | 1.1 | 1.1 | 2.2 | 2.2 |
| Weight(kg) | 750 | 800 | 900 | 1000 |
| Outline dimension (L×W×H) mm | 3200×1150 ×1550 | 3200×1350 ×1650 | 3200×1550 ×1750 | 3400×1750 ×1850 |
| Heating power (kw) | 2 | 3 | 4 | 4 |
Plastic bags are more and more important in packaging industry because of its excellent isolation property. GFQ single layer plastic bag making machine can produce high quality plastic bags. It is easy to operate this machine, and the mechanical shock is little due to gradual start. Then unqualified products can be reduced. Heating sealing process is used and can make sure that plastic bag bottom is strong and there is no leak. Auto counting device is also installed and can tell operators how many plastic bags have been produced. Materials also can be unloaded or reset automatically, thus reducing labor cost and improving production efficiency.
As an experienced single layer plastic bag making machine manufacturer based in China, we at Zhuxin Machinery also provide horizontal slitting machine, food paper bag making machine, blown film machine, film packaging machine, and more.
