1. Instead of traditional indexing box, Geneva drive is introduced in key parts of our machines. In this way, defects, such as low stability during high speed operation caused by traditional driving box and chain drive could be well prevented. Meanwhile, driving could be more accurate, working speed could be higher, and the performance could be highly improved.

2. Fully automatic lubrication system is introduced in the bottom part of our paper cup forming machine, thus to create a stable and durable running at high speeds for very long periods of time. Besides, an automatic oil circulating and filtering system is introduced for multi-layer filtering, which helps to ensure the durability and reliability of our paper cup forming machine.

3. The inner structure of our paper cup forming machine is optimized, thus compact structure, small size, and easy transportation could be achieved.

4. All the components used in our machine underwent a standard production. Holes installed on the bottom of our paper cup forming machine, as well as the parallelism of our installation tables are all well positioned with large-scale CNC lathe. Thus, components become more standard and interchangeable, and machine’s maintenance becomes easier.

5. Main motor of our paper cup forming machine is equipped with brakes, so when detection is required during power off or commissioning, the positioning will become more accurate and the operator’s security will also be well protected.
