Advantages 1. Adopt the Anilox roll to transfer ink. 2. Unwinding and rewinding are all controlled by magnetic particle brake, clutch, or by automatic tension controller of Mitsubishi, made in japan. 3. Each printing unit adopts 360-degree registering adjuster. 4. Each printing unit has one IR (infrared) drier. 5. The roller can break away automatically when the machine stops to run, or runs at a low speed, in order to avoid ink being dry.
| General power | 25kw | ||
| Printing speed | 60m/min | ||
| Printing color | 2 | 3 | 4 |
| Max. Roll width | 860mm | ||
| Max. Printing width | 850mm | ||
| Max. Feeding Roller diameter | 1400mm | ||
| Max. collector roller diameter | 1400mm | ||
| Printing grith | 180-420mm | ||
| Registering precision | ±0.15mm | ||
| Weight | 3800kgs | ||
| Measurement | 3500*1850*2200mm | ||
| Voltage supply | 380v 50hz or can be customized | ||
