Features
  • High quality bearing, rubber roller and needle bed
  • Features a durable construction, quiet operation, high operational stability, and easy control
  • The noise level and electrical safety levels are in full compliance with international safety standards.
Technical Parameters
  • Working Width: 28 inch (710mm)
  • Number of needles per inch: available with 10, 12, 14, 15, 16, 18, 20
  • Weft Guide Bar: 8 bars
  • Max. Fabric Width: 70mm (250mm optional)
  • Motor Power: 1.5kw
  • Speed: 1500 rpm/min
Machine Specifications
  • Machine Weight: 900kg
  • Creel Weight: 120kg
  • Packing Size (machine): 1850*1150*1650mm
  • Packing Size (creel): 2600*300*300mm
Accessories
Control system for auto stop motion during yarn breakage 1 set
Variable frequency drive for automatic speed adjustment 1 set
Automatic stop motions for incorrect product winding 1 set
Automatic oil circulating system 1 set
Tri-roller feeding system for elastic materials 2 sets
Double sided winding system for finished narrow fabrics 1 set
Steel reed for warp and weft yarns 1 set
Indicating light for stop motions 1 pc
Creel with 200 bobbin numbers + 4 warp beams on a frame(other specifications available) 1 set
