Usage This machine is adapted to medicines . foods ,health care products. cosmetics, audio and video products and other related square boxes decorating. such as : medicine box ,chewing gum, health care products. tea , sugar ,condoms, rubber , mosquito-repellent incense, cigarettes, tapes , CDS VCD (CD), playing CARDS, transparent soap, batteries, floppy disk played anti-counterfeiting, etc, and Improved the product specification, increased value-added products. This machine can be linked with the boxes machine production.
Features
1. Compact structure, stable performance, convenient operation and maintenance.
2. Using the multi-function digital converter, stepless speed changed.
3. Mould replaced convenient and flexible.
4. With automatic feeding materials and counting function.
5. Transmission parts have protection devices and troubleshooting tips.
6. With trial film feeding clutch to saving packaging materials.
Main Technical Parameters:
Model | BTB-200A |
Packaging Speed | 40-80 cases/min |
Packaging Material | BOPP film and anti-fake gold arrows |
Packaging Size | (length)50-160mm (width)20-100mm (thickness)8-50mm |
Machine Size | 2000×790×1550mm (L×W×H) |
Machine Weight | (about)600Kg |
Power Supply | 220V 50HZ |
Total Power | 4.5kw |
